ESAW Tunnel Diode Characteristic Apparatus (EEC-11439)In built DC regulated Power Supply of 5 volts. Two3½digit digital panel meter for measuring the voltage across resistance & tunnel diode (Range 0-2V DC). Current control on the front panel. TunnelDiode-IM3717

ESAW Millman's Theorem (EEC-11448)Instrument comprises of one fixed voltage 5 V&another 1.2 V to 10 V, DC regulated power supply. Two moving coil analog meter 10 V & 20 mA are mounted on the front panel to measure voltage & current, circuit diagram is printed & important connectio...

ESAW Thevinin's Theorem (EEC-11457)Instrument comprises of Variable DC Regulated variable Power Supply of 1.2 V to 10 V. Two moving coil meters of 10 V & 10 mA are provided to read voltage & current. Circuit diagram Printed on the front panel & connections of Supplies, Meters & Re...

ESAW Reciprocity Theorem (T-11467)Instrument comprises of Variable DC Regulated Power Supply of 1.2V to 10 V. Three moving coil meters 10V, 10mA & 20mA are provided to read voltage & current. Circuit diagram Printed on the front panel & connections of Supplies, Meters & Resistance...

ESAW Super Position Theorem (T-11476)Instrument comprises of Two fixed Voltage DC Power Supply of 5V & 9V. Two moving coil meters 10V & 10mA are provided to read voltage & current. Circuit diagram Printed on the front panel & connections of Supplies, Meters & Resistances are b...

ESAW Basic Logic Gates (EEC-11485)Instrument comprises of 5V/150mA DC Regulated Power Supply for logic '1' logic '0'. TTL IC's for 'AND', 'OR', ‘NOT’, ‘NAND’, ‘NOR’, ‘EX-OR’ 'EX-NOR' gates. Components soldered on the back side of hylum  sheet and front panel connections are brought out at sockets...

ESAW Digital Trainer Kit (EEC-11494)It consist of fix voltage power supply of 5 volts for IC’s. Two number logic input switches and 1 number logic output indicator. All the above 5 gates are mounted on the panel with their respected 14 pin IC. Every pin of each IC is connected to the socket with ...

ESAW Digital Trainer Board (EEC-11503)Instrument comprises of DC Regulated Power Supply 5V/150mA, 2 logic '1' 2 logic '0' inputs are provided on sockets, 2 Red LED output indicators, circuit diagram printed for 4 'NAND' 4 'NOR' gates and their respective IC's placed inside the cabinet. Connection...

ESAW Basic Logic Gates using discrete components Kit (EEC-11512)Instrument comprises of DC Regulated Power Supplies 5 VDC/150mA, + 15 VDC/150mA, 1 voltmeter, 4 SPDT switches provided for selecting logic '1' logic '0', one output indicator, Circuit diagram for weighted resistor network inverting c...
