ESAW Boltzman Constant Kit (EEC-11521)The experimental kit provides the following facilities:(a) A digital millivoltmeter (0 -9.99 V) to measure the voltage across the diode.(b) A highly stabilized power supply whose voltage can be varied in steps of 1mV using a ten turn potentiometer.(c) A digit...

ESAW Lattice Dynamics Kit (EEC-11530)It consists of an Audio oscillator with amplitude control and facility to vary the frequency from 0.9 KHz to 90 KHz. It has built in power supply and output stage to match the impedance of simulated lattice. Another part of Lattice Dynamic Kit consists of tran...

ESAW Applications of IC 555 (EEC-11539)Instrument Comprises of DC Regulated power Supply 5 V DC/150 mA, IC 555 & various components kept inside the cabinet&connections are brought out at 4mm sockets.

ESAW Hartley Oscillator (EEC-11548)Hartley's Oscillator is intended for generation of high frequency signal slike carrier wave signals in a communication system. This consists of a Tank circuit made up of an inductor and a fixed capacitor shutted by a voltage variable capacitor network.Using this...

ESAW Capacitance And Permitivity Kit (EEC-11566)• Completely self contained : no othermeasuring instrumentsare needed.• No calibrationrequired.• High sensitivity : change of the order of 0.1 nf can easily bedetected.• Integrated circuit electronics.• Linearity betterthan 1%f.s.d.In operation it p...

ESAW Operational Amplifier Trainer IC-741 (EEC-11575)Complete Kit (Digital) in all respects with the following buit-in components:-• Built-in + 1.2V power supply forIC 741.• 0-5V, 0-5V: 2 continuously variable power upply.• Spare resistances 22K, 4.7K, 3.3K : 1 no. Each ,47K, 1K, 33K:2 nos Each&a...

ESAW Digital Control System (EEC-11584)Specifications• Second orders imulated process(analog Process)• Built-in D/A and A/D circuits(8-bit)• 8085 based P-kit as digital controller with user software in8K EPROM• 16- bit arithmetic for algorithmic calculations• Square wave test input(internal)• 16 ...

ESAW Compensation Design (EEC-11602)Specifications• Simulated “uncompensated” system having adjustabledamping. Peak percentovershootM variable P, from 20% to50%,and steady state errorvariablesfrom50%to0.5%• Compensation network implementation through built-invariable gain amplifier.Gain is adjust...

ESAW Light Intensity Control System (EEC-11611)Specifications:• Built-in 3½ digit DVM• Built-in IC regulated power supplies• Literature and patch cords included• Seven lamps 6V/300mA• 5Hz square wave and triangular wave for dynamic response study
