Advance Trinocular Microscope

Advance Trinocular Microscope

Model No : ATM-01

Regular price Rs. 37,999.00
Shipping calculated at checkout.
Quantity:
Estimated Delivery:
Tags:

Advance Trinocular Microscope

Advance Trinocular Microscope Exporter

Advance Trinocular Microscope in india

Advance Trinocular Microscope manufacturer in India

Get It Today

Free shipping

Free shipping on orders over $75.

100 - Day Returns

Not impressed? Get a refund. You have 100 days to break our hearts.

Dedicated Support

Support from 8:30 AM to 10:00 PM everyday

Advance Trinocular Microscope

Regular price Rs. 37,999.00
Quantity:
Description

    This newly designed ESAW microscope model features improved optics and a sleek, ergonomic design. This series of microscopes features high-quality optical and mechanical components that offer reliable functionality for years of use. The illumination system (CE approved with universal power supply) is variable and available in two formats, halogen and LED making it cordless with the supplied rechargeable battery.

    These are configured with a Wide Field 10x eyepiece, quadruple nosepiece with Semi-Plan Objectives, mechanical stage and sturdy stand with extended base for enhanced stability and comfort. There are a variety of options and accessories available including binocular & trinocular bodies.

    Product Information

    MAIN BODY  HIGHLY RIGID, VIBRATION FREE SINGLE PIECE (BASE, COLUMN & ARM) ALUMINUM ALLOY CASTING, WITH TRANSMITTED LIGHT,POWER SUPPLY & BRIGHTNESS CONTROL INTEGRATED IN THE BASE. THE FRAME IS STABLE,STRONG, BIG & EASY TO CARRY. PUREWHITE BODY WITH BLUE ON THE BOTH SIDES, IS FRESH AND VIVID DESIGN.
    OPTICAL SYSTEM INFINITY COLOR CORRECTED OPTICAL SYSTEM
    VIEWING  30° INCLINED SIEDENTOPF BINOCULAR HEAD, INTERPUPILLARY DISTANCE: 50-75MM, +5 DIOPTER ADJUSTABLE, 360° ROTATABLE
    OBJECTIVE  SEMI PLAN ANTI FUNGUS OBJECTIVE 4X, 10X,
    FOCUSING 40X (S) AND 100X OIL, (S)
    LIGHT SOURCE  LIGHT SOURCE: ILLUMINATION SYSTEM LED 3.5W 3V WITH INTENSITY CONTROL REGULATOR, UNIVERSAL POWER SUPPLY 110V - 240V, CE APPROVED.
    EYE -PIECES  WIDE FIELD EYEPIECE 10X, FOV 18MM WITH DIOPTER SETTING
    FOCUSING MOVEMENT COAXIAL COARSE AND FINE FOCUSSING MECHANISM, WITH MAXIMUM
    HEIGHT LOCKABLE CLIP. ERGONOMICALLY DESIGNED FOR EASY GRIP.
    FOCUSSING RANG-30MM
    STAGE  GRADUATED DOUBLE LAYER MECHANICAL RECTANGULAR STAGE, SIZE 140 X 140MM WITH CROSS TRAVEL 90MM (X) X 65MM (Y) ON BALL BEARING WITH CO-AXIAL CONTROLS.
    NOSEPIECE  BALL BEARING LOADED, INWARD QUADRUPLE NOSEPIECE WITH PRECISE, POSITIVE STOPS FOR CENTERED ALIGNMENT OF OBJECTIVES.
    MAGNIFICATION SETTING   8 MAGNIFICATION SETTING: 40X, 60X, 100X, 150X, 400X, 600X, 1000X & 1500X
    CONDENSER  CENTERABLE ABBE CONDENSER, NA 1.25 WITH ASPHERIC LENS.
    PACKING & ACCESSORIES  CARRYING CASE: STYROFOAM PACKING & OUTER CORRUGATED BOX SUPPLIED WITH: USER MANUAL, VINYL! DUST COVER, CLEANING CLOTH AND 01 UNITS FUSES
