BIOSAFETY CABINET CLASS II TYPE A2

BIOSAFETY CABINET CLASS II TYPE A2

Model No : BISC-01

Shipping calculated at checkout.
Quantity:
Estimated Delivery:
Get It Today

Free shipping

Free shipping on orders over $75.

100 - Day Returns

Not impressed? Get a refund. You have 100 days to break our hearts.

Dedicated Support

Support from 8:30 AM to 10:00 PM everyday

Quantity:
Description

    ESAW range of Bio safety Cabinets is designed for product, personal and environmental protection. They are suitable for general microbiological work with agents assigned to bio safety levels 1, 2 or 3. These Biological Safety Cabinets are ideally used in hospitals, clinical research, life science and pharmaceutical laboratories. These units are comes with sliding shattered proof glass view screen, base stand, removable work tray, supply filter and HEAP filters. These biological safety cabinets can be exhausted outside the room.



    • Large front panel display and user friendly control panel
    • 10° slanted view screen provides highly visible and easily accessible area
    • Work area is surrounded by negative pressure, double-wall plenums for superior protection
    • Sturdy construction of cabinet protects from air leakage from the working zone
    • Display of Life of UV lamp, HEPA filter and temperature
    • Caster wheels for ease of mobility
    • Levelling jack for vibration free operation

    Product Information



                                          Technical Specification

    Cat. No.

    LBS-32A2

    LBS-42A2

    LBS-52A2

    LBS-62A2

    Working Area (mm)

    900×600×600

    1200×600×600

    1500×600×600

    1800×600×600

    External Size with stand (mm)

    1020x800x2260

    1320x800x2260

    1620x800x2260

    1920x800x2260

    Inflow Velocity (m/s)

    0.53 ± 0.025

    Down flow velocity (m/s)

    0.33 ± 0.025

    Control system

    PLC / Manual

    Display

    Colour HMI with touch screen / Deferential pressure Gauge

    Air Flow system

    70% air recirculation and 30 % exhaust

    Front sash

    Toughened glass

    Maximum opening (mm)

    400

    Safe Opening (mm)

    200

    Filter

    HEPA filter 99.999 % efficient

    Particle Retention

    0.3 microns

    Class

    100

    U V lamp

    1

    Base Height (mm)

    635

    Noise level (dB)

    ? 65

    Exhaust Volume (m3/h)

    936

    1315

    1645

    1972

    Down flow Volume (m3/h)

    626

    835

    1045

    1253

    Power

    300

    350

    400

    800

    Voltage

    230 VAC

    Packing Size (mm)

    1147x930x1800

    1447x930x1800

    1747x930x1800

    2050x930x1800

    Net weight (kg)

    200

    225

    250

    275

    Gross weight

    250

    275

    300

    325
