Construction

8 Portable

8 Body made of CRC sheet duly furnished with power coating.

8 The front of tube Sealer is made of Stainless Steel covering and stainless steel Splash Guard.

8  The body is fitted with 4 rubber feets.

8 It is also fitted with a Flap of carry the Machine.

Specifications

Specifications

8 Microprocessor based control system.

8 Very stable and reliable working.

8 Working Voltage Range: 220 Volts+10%,50 Hz A.C.

Technical Parameter

8 Sensor: Automatic Senses Blood Bag Tube

8 LED Update: Ready to Seal, sealing in process, scaling completed through LED indication lights.

8 Splash Guard: Splash Guard for technical Safety (So Blood don’t splash on technician)

8 Sea; Time: 1.3 Sec. to 1.5 Sec.

8  Frequency: RF Fr. 40.68

Weight and Dimension

8 Weight - 5 kg. Approx.

8 Dimensions (LxWxH) - 350x190x170 mm
