Fluorescence Inverted Microscope
Model No : iV-60
Regular price
Rs. 899,999.00
Shipping calculated at checkout.
Share Products
Estimated Delivery:
Get It Today
Free shipping
Free shipping on orders over $75.
100 - Day Returns
Not impressed? Get a refund. You have 100 days to break our hearts.
Dedicated Support
Support from 8:30 AM to 10:00 PM everyday
Fluorescence Inverted Microscope
Regular price
Rs. 899,999.00
Description
Description
- Description
- Long lifetime, stable output to ensure effective excitation
- Digital screen show and remember light intensity
- Strong light intensity Of short light path, reliable and safety
- Easy to use, no need debugging, instant ON/OFF
- Varies of fluorescence filter groups
- Compatible to microscopes in world famous brand
- Professional customize solution for different users
- Fluorescence module is removable, upgrading to 5 channels with 3/4 color fluorescent band optional
ESAW iV-60 is composed of LED epi-fluorescence system and inverted biological microscope. It adopts excellent infinite optical path, long working distance plan achromatic objectives and wide field eyepiece.The compact and stable high rigid body satisfied the anti vibration requirements of microscope operation. Modular design provides safely and quickly lighting adjustment and switch of fluorescent filter groups. The microscope is used for microscope observation of cell tissue and transparent liquid tissue, as well as fluorescence observation in the fields of bio-pharmaceutical, medical detection, disease prevention, etc.
Product Information
| ITEM | SPECIFICATION |
| Eyepiece | SWF10X /22Splan eyepiece ,high eyepoint Centering telescope |
| Observation tube | 45°inclined ,Interpupillary distance 53-75mm,diopter is adjustable |
| Objectives | Long working distance plan M -UPLFLN4X /0.13Work distance :17.15mm |
| Infinity long working distance achromatic plan 10X/0.25Work distance :4.1mm | |
| Infinity long working distance achromatic plan40X /0.58Work distance :2.5mm | |
| Infinity long working distance achromatic phase contrast plan 10X/0.25PhWD :4.1mm | |
| WD :2.5mm Infinity long working distance achromatic phase contrast plan20X /0.45Ph | |
| Epi -fluorescence illumination system | Cold LED light source ,brightness continuously adjustable |
| Standard with three excitation filter groups ,other filter groups are optional | |
| Excitation filter Excitation wavelength | |
| Ultraviolet UV )360-390nm | |
| Blue (B )460-495nm | |
| Green (G )528-553nm | |
| Focus system | Coaxial coarse /fine focus ,with tension adjustable and up stop ,minimum division of fine focusing. |
| Nosepiece | Quintuple nosepiece ,ball bearing with anti fungus device |
| Stage | Glass rotundity stage overall size is $118mm,inner size is $68mm |
| Culture dish holder 186mmx129.5mm,suitable for circular culture dish 90mm | |
| Culture dish holder 234mmx77.5mmsuitable for circular culture dish $68.5mm | |
| Culture dish holder 357mmx82mmsuitable for circular culture dish 60mm | |
| Culture dish holder 429mmx77.5mm,suitable for circular culture dish #35mm | |
| Transmitted | White LED lamp with brightness adjustable |
| illumination | Push -pull type condenser ,numerical aperture 0.3 |
| system | Green filter |
| Light baffle | 110mmx 70mm |
| Condenser | Push -pull type condenser ,working distance 55mm |
| Lighting system | 9WLED with brightness adjustable |
| Camera adapter | Internal set 0.75XC -mount |
