Microscope Cameras for high-quality digital imaging and capturing detailed microscopic views for research and education

Microscope Cameras

Model No : MD-Series

Regular price Rs. 9,999.00
Shipping calculated at checkout.
Quantity:
Estimated Delivery:
Collections:Microscope Cameras and Screens, Microscopes
Delivery Period

3-5 Working Days

Replacement

3 Days Replacement as standard, Free of Cost

Dedicated Support

Support from 9:30 AM to 6:00 PM everyday

Microscope Cameras for high-quality digital imaging and capturing detailed microscopic views for research and education

Microscope Cameras

Regular price Rs. 9,999.00
Quantity:
Description
Description
Description
  • Description

    Features MD-130

    Digital imaging module: Wider dynamic range 1.3MP imaging module;
    Imaging software: Future Win Joe microscopic imaging program;
    Optical matching: Built-in relay lens and field lens;
    Camera house: compact and light-weight round-shaped shell.

    Features: MD-300

    Digital imaging module: YUY2 and MJPG of image format 2048*1536 USB imaging module;
    Imaging software: Future Win Joe microscopic imaging program
    Optical matching: Built-in relay lens and field lens;
    Camera house: compact and light-weight round-shaped shell.

    Features: MD-500

    Digital imaging module: YUY2 and MJPG of image format 2592*1944 USB imaging module;
    Imaging software: Future Win Joe microscopic imaging program
    Optical matching: Built-in relay lens and field lens;
    Camera house: compact and light-weight round-shaped shell.

    Product Information

    Capture Mode Picture and Video Picture and Video Picture and Video
    Sensor Parameter 1/3 1.3MP 1/2 3.0MP 1/2.5” 5.0MP
    Max. Resolution 1280*1024 2048*1536 2592*1944
    Pixel Size 2.2?m*2.2?m 2.2?m*2.2?m 2.2?m*2.2?m
    Responsivity 1.0V/ lux-sec 1.4V/lux-sec 1.4V/lux-sec
    Dynamic Range 71dB 70.1dB 70.1dB
    S N Ratio 44dB 38.1dB 38.1dB
    SpectraL Range 400-650nm(with IR-filter) 400-650nm(with IR-filter) 400-650nm(with IR-filter)
    Frame Rate 17fps@1280*1024 15fps@2048*1536 10fps@2592*1944
    Preview Model 1280x1024,1280x800, 1024x768,800x600, 640x480, 352x288,320x240, 320x240640x480,352x288 2048x1536,1600x1200, 1280x1024,800x600,640x480,352x288,320x240 2592x1944,2048x1536, 1600x1200,1280x1024, 800x600, 640x480, 352x288,320x240
    Exposure ERS or Manual ERS or Manual ERS or Manual
    Power Consumption 190mW 381mW 381mW
    White Balance Auto Auto and manual Auto and manual
    Power Supply USB Powered USB Powered USB Powered
    Device Weight 0.09kg 0.09kg 0.09kg
    Device Size ?74.00mm*97.00mm 97mm*?74mm 97mm*?74mm
    Cable length 1.5m 1.5m 1.5m
    Function of Software Image & video Capture,Edit and Management Image & video Capture,Edit and Management Image & video Capture,Edit and Management
