Salt Spray Corrosion Test Chamber

Salt Spray Corrosion Test Chamber

Model No : SSC-108

Shipping calculated at checkout.
Quantity:
Estimated Delivery:
Delivery Period

3-5 Working Days

Replacement

3 Days Replacement as standard, Free of Cost

Dedicated Support

Support from 9:30 AM to 6:00 PM everyday

Quantity:
Description

    Salt Spray Test Chamber or Salt Fog Test Chambers are made for testing corrosion resistant properties of metal parts, zinc plated nut and bolts, surface coating and paint. In such chambers coated samples are put under arti?cial corrosion environment inside the chamber to evaluate how suitable the coating surface is to use as protective ?nish on ?nal products. Samples are examined under test at pre-determined amount of time; higher the corrosion resistivity longer will be the test time duration.

    • Easy loading and unloading of large samples
    • Digital microprocessor based control
    • Auto water refill system
    • Auto Fog Collection System
    • Over temperature alarm
    • Low water alarm
    • Durable construction
    • Energy efficient design

    Product Information

    Model No. SSC-108 SSC-125 SSC-270 SSC-600 SSC-800 SSC-1000
    Dimensions In MM 600 x 450 x 400 600 x 450 x 450 900 x 600 x 500 1200 x 1000 x 500 1600 x 1000 x 500 2000 x 1000 x 500
    Capacity 108 Ltrs. 125 Ltrs. 270 Ltrs. 600 Ltrs. 800 Ltrs. 1000 Ltrs.
    TEMPERATURE RANGE  35°C ±1°C /50°?±1°C
    TEMP .OF PRESSURE BARREL  47°C ±1°C /63°C ±1°C
    TEMPERATURE UNIFORMITY  +2°C
    TEMPERATURE FLUCTUATION  ±0.5°C
    TEMPERATURE SENSOR  Pt100
    HUMIDITY RANGE  >93%(No Controlled /Display )
    CONTROLLER TYPE  02No. PID temperature controllers for chamber and pressure vessel
    TIMER  Digital timer 9999hours
    CANOPY  Made of Acrylic ,Manual lifting
    CHAMBER CONSTRUCTION  PVC reinforced hard plastic sheets for complete corrosion proof construction
    BRINE TANK (RESERVOIR ) 25liters inbuilt brine tank ,Low water level indicator
    SALT FOG FALLOUT RATE  1~2mlper 80cm2per hour
    SPRAY MODE  Continuous or intermittent spray
    COMPRESSED AIR PRESSURE  1.00+0.01kgf/cm²
    SAMPLE RACKES  08Nos .V type racks ,12Nos .support rods
    FOG ACCESSORIES  01.No. Spray tower ,02Nos .cup collectors, Mains ON /OFF ,Pressure regulator ,Dial type pressure gauge ,
    STANDARD FITTINGS  Drain system ,Spray solenoid valve
    SAFETY FEATURES  Over temperature protection ,Low water protection
    POWER SUPPLY  220Volts 50Hz
