The Ultimate Trainer Microscope is designed for educational and research facilities looking for table-top magnification systems that can provide a long working distance, bright and homogenous LED illumination, and super resolution images all in a compact form factor with fluid maneuverability. Our MaxLite™ coated apochromatic magnichanger promises high color fidelity in three color wavelengths. A well designed arm enables a lower center of gravity, ensuring a well balanced and vibration free microscope that won't monopolize your workstation.
| Microscope carriers | 120° carrier |
| Eyepiece | WF 10X/18mm with retractable eye guards, diopter adjustment ± 5mm with diopter lock; optional: WF 12.5X/18mm |
| Objective | f-250 mm with fine focus (standard); Options: NuVar with focal length adjustment f-300-400 mm, f-200-400 mm; f-300 mm or f-400 mm with fine focus; f-200 mm fixed objective; objective lens protector. |
| Light Source | 50W LED; 100,000+ Lux |
| Built-in-Filters | Green & Yellow |
| Binocular Tube | 0-210° tiltable ergonomic head |
| Vertical Movement of arm | ± 250 mm, power saving feature with light cut-off in park position |
| Apochromatic Magnichanger | 5 step: 0.4X, 0.6X, 1.0X, 1.6X, 2.5X |
| Package Contents | Tools for securing table mount |
| Mounting Options | Table mount only |
| Accessories (Optional) | Beam splitters (straight/inclined) |
| Rotoplate and/or extender | |
| Proline range of camera/video adapters | |
| NuVar variable working distance objective | |
| Spacers and extender arms |
