Approximate Size and Weight
L : 175mm+5mm
W : 105mm+5mm
H : 118mm+5mm
Weight (Min) : Approx 2kg
Technical Specifications
1. Housing Enclosure: Compact, Portable, Light Weight.
8
It is moulded type made of ABS Plastic and is Shock Proof
8 Suitable sliding tray made of ABS lined with SS material of thickness 0.8mm (minimum) on the side walls as well as the bottom of the tray is provided for collection of residue and destroyed tips syringe.
8 Suitable provision to burn the needle and to cut the syringe tips are provided in the unit.
8 It complies in general to the requirements of IS: 302 (Part-1) 1979 to ensure safe and reliable operation in normal use.
Manual Cutter:- Fitted with High Carbon Cutter to cut Syringe Hub.
Capacity:- The unit is having adequate capacity to destroy all kinds and following size of injection needles Dia ranging from 24G upto 18G
Power Switches:- Power on/off switch is provided along with power on indicator. The unit is also provided with fuse of adequate rating. The item quoted is also provided with power cord of 1.5 meter and an earthing point.
Power Requirements :- Power 230V+10%50HZ AC supply requirement. The following are the power requirements.In Stand-by mode maximum upto 3 watt.
-
During destruction of thickest needle of 18G maximum Power requirement/power consumption is maximum 5 amp at 230VAC.
-
The 5 pieces of injection needle of 18G upto full length as available in market can be destroyed in continuous operation
Power Requirements :Power 230V+10%50HZ AC supply requirement. The following are the power requirements.
