PX-10i Penta Head Biological Microscope

PX-10i Penta Head Biological Microscope

Model No : PX-10i

Regular price Rs. 1,490,999.00
Shipping calculated at checkout.
Quantity:
Estimated Delivery:
Get It Today

Free shipping

Free shipping on orders over $75.

100 - Day Returns

Not impressed? Get a refund. You have 100 days to break our hearts.

Dedicated Support

Support from 8:30 AM to 10:00 PM everyday

PX-10i Penta Head Biological Microscope

Regular price Rs. 1,490,999.00
Quantity:
Description

    Multi-viewing demonstration biological microscope is designed for several people to observe one specimen together at the same time. It has infinity imaging system, high light intensity illumination system, sharp & clear image and consistent image in observation. Particularly it is suitable for discussion application in Clinic, Research and education. It supplies bigger space for an observer that brings more comfortable in working.

    The microscope is equipped with LED cursor to indicate image in the viewing field, the cursor is arrow type with light intensity adjustable button. The cursor can be mover freely; any position of the image can be indicated.

    Product Information

    Optical system  Infinite Optical System
    Viewing head  Compensation Free Trinocular Head Inclined at 30° ( 50mm-70mm )
    trinocular =100:0/20:80/0:100.
    4-Binocular head, interpupillary distance adjustable 50mm-75mm
    9-Binocular head, interpupillary distance adjustable 50mm-75mm
    Eyepiece  Plan WF10X/22mm
    Objective  IOX series infinity plan objective  4X0.10 ? 10X/0.25? 40X/0.65? 100X/1.25 Oil
    Nosepiece  Quintuple Nosepiece, Inward ball bearing type
    Middle module  Middle module with LED cursor ,three colors red /green /blue for option ,intensity adjustable .
    Stage  X-axis rackless Double layers mechanical stage
    stage size : 190mmx 160mm
    Moving range: 80mmx 50mm
    Focusing Kohler illumination with aperture iris diaphragm and field iris diaphragm
    Halogen Bulb 12V/100W, AC85V-230V
    brightness adjustable
    Indicator LED cursor brightness adjustable
    Certifications European Ce, ISO:9001 ISO:13485, USFDA
    Optional Acessory Eyepiece WF15X/17mm,WF20X/12.5mm
    infinity plan objective 20X0.40,60X/0.85
    infinity semi-plan objective 4X0.10 ? 10X/0.25? 20X/0.40? 40X/0.65? 60X/0.85? 100X/1.25 Oil
    Photography attachment and CCD C-mount:0.5X?0.57X?0.75X
    1.3Mega?2.0Mega?3.0Mega?5.0Mega?10.0Mega
    CMOS Digital camera eyepiece
    HDMI 1080 and HDMI720p cameras
    Image analysis software
