Solar Panel Test Chamber

Solar Panel Test Chamber

Model No : SPTC-125

Shipping calculated at checkout.
Quantity:
Estimated Delivery:
Delivery Period

3-5 Working Days

Replacement

3 Days Replacement as standard, Free of Cost

Dedicated Support

Support from 9:30 AM to 6:00 PM everyday

Quantity:
Description

    Thermal Cycle Test: Thermal cycle test is performed according to IEC 61215:2005 standard to test ability of PV module to withstand effects of temperature stress. This test is performed between temperature 85°C and -40°C with fast changing rate. Number of cycles is run 50 or 200 times.

    Humidity Freeze Test: Humidity freeze test is performed to determine ability of PV modules withstand against high temperature and humidity conditions followed by sub-zero temperature. In this this 10 cycles are run between 85°C with 85% relative humidity and negative temperature -40°C.

    Damp Heat Test: Damp heat test is performed to test effects of long exposure of humidity penetration and high temperature. In this test is performed by applying 85°C ±2°C temperature with relative humidity of 85% for uninterrupted cycle of 1000 hours.

    Product Information

    TEMPERATURE RANGE  -60°C to 100°C
    TEMPERATURE FLUCTUATION  ±0.5°C
    TEMPERATURE DEVIATION  ±2.0°C
    HUMIDITY RANGE  20%to 98%RH
    HUMIDITY DEVIATION  ±2.5%RH
    TEMPERATURE CHANGE RATE  1to3.4°C /Min
    TEMPERATURE SENSOR  Class A Pt100
    HUMIDITY SENSOR  Dry and wet bulb sensor
    AIR CIRCULATION  Centrifugal blower system
    CONTROLLER  color LCD touch screen controller ,100programs with 100segments,Temperature ,Humidity and Time settings ,In -built data recording
    PANEL SIZE  1x 2meter
    PANEL CAPACITY  4/6/8/10/12panels
    TEST PARAMETER  Thermal Cycle Test :50or 200cycles from -40°C to +85°C, Humidity Freeze Test :10cycles from +85°C ,85%RH to -40°C , Damp Heat Test :1000hours at 85C,85%RH
    COOLING SYSTEM  Mechanical compression refrigeration system
    REFRIGERATING UNIT  French TECUMSEH compressor
    REFRIGERANT  R404A ,R23
    HEATING ELEMENT  Nichrome heater
    DATA RECORDING  Ethernet connection ,PC Link ,USB
    EXTERIOR MATERIAL  Powder coated steel sheet
    INTERIOR MATERIAL  Stainless steel 304
    WATER SUPPLY SYSTEM  Automatic water supply
    HUMIDITY SYSTEM  Stainless steel surface evaporation humidity system
    DEHUMIDIFICATION  Evaporator
