Surgical Ultimate Motorised Microscope

Surgical Ultimate Motorised Microscope

Model No : UM-12

Regular price Rs. 1,590,999.00
Shipping calculated at checkout.
Quantity:
Estimated Delivery:
Delivery Period

3-5 Working Days

Replacement

3 Days Replacement as standard, Free of Cost

Dedicated Support

Support from 9:30 AM to 6:00 PM everyday

Surgical Ultimate Motorised Microscope

Regular price Rs. 1,590,999.00
Quantity:
Description

    A sturdy workhorse in the most demanding of surgical environments. Built-in modularity and optional filter packages provide added versatility in Ophthalmic retinal and cataract surgery as well as Neurosurgery.  A proprietary pyramidal stand helps quickly offset weight as the arm rotates, keeping the system vibration-free and easy to maneuver. Apochromatic optics, compatibilty with image inverters, and a host of video and ergonomic accessories make Ultimate a value leader.

    Product Information

    • Apochromatic Magnichanger

      Motorized 5-steps: 0.4X, 0.6X, 1.0X, 1.6X, 2.5X; tilt-able with auto lock

    • Eyepiece

      Standard: WF 10X/18mm with eye guards Optional: WF 12.5X/18mm with eye guards All eyepieces have diopter adjustment ± 5 mm and diopter lock

    • Vertical Movement of arm

      ±300 mm

    • Microscope carriers

      10 function wired foot switch for xyz, magchanger & intensity control. Z-axis 40 mm, motorized noise free, 50 X 50 mm XY with auto reset

    • Binocular Tube

      0-210° Binocular tiltable head

    • Arm

      Swivel 470 mm, Suspension 1000 mm

    • Built-in-Filters

      Daylight, blue barrier (yellow filter), fluorescein excitation (cobalt blue), vascular identification (green filter), anti-glare (two spot diaphragm) and retinal protection interoperative viewing modes

    • Stand

      Robust "Pyramid" stand for counter balancing, vibration-free base with four lockable castors

    • Light Source

      UV & IR free 50W LED

    • Objective

      Standard: f=200 mm, Optional: f=175 mm

    • Accessories (Optional)
      • Assistant binocular attachment, Proline range of camera adapters, Smart phone adapters
