The Ultimate MU ENT Microscope is intended for routine inspection and in screening clinical environments. A well-designed apochromatic optical system with a high output LED built directly into the microscope housing provides users with a compact solution. The arm system has been carefully designed to mitigate vibration and lower the system's center of gravity to provide a more stable, lighter weight solution.
Product Information
Eyepiece
WF 10X/18mm with retractable eye guards, diopter adjustment ±5mm with diopter lock; optional: WF 12.5X/18mm
Binocular Tube
45° inclined (standard), 0-210° inclinable, straight head (optional)
Apochromatic Magnichanger
0.6X, 1.0X, 1.6X
Built-in-Filters
Green & Yellow
Vertical Movement of arm
± 250 mm, power saving feature with light cut-off in park position
Mounting Options
Floor stand, wall mount and ceiling mount
Objective
f-250 mm with fine focus (standard); Options: NuVar with focal length adjustment f-300-400 mm, f-200-400 mm; f-300 mm or f-400 mm with fine focus; f-200 mm fixed objective; objective lens protector.
Light Source
27W LED / 75K lux
Stand
H-base on 4 locking castor wheels
Microscope carriers
120° carrier
Package Contents
Tools for Securing Base and Pillar, Sterilizable Knob Covers, Nylon Dust Cover
