ZX-63 Digital Microscope
Model No : ZX-63 D
Shipping calculated at checkout.
Share Products
Estimated Delivery:
Get It Today
Free shipping
Free shipping on orders over $75.
100 - Day Returns
Not impressed? Get a refund. You have 100 days to break our hearts.
Dedicated Support
Support from 8:30 AM to 10:00 PM everyday
Description
Description
- Description
- 20mm Wide Field Eyepieces
- Swinging Adjustment of View
- Ring Illumination Light
- Auxiliary Lens
- Trinocular with Camera Option
- LED Incident and Transmittal Light (Standard)
- Integrated Control for LED Light
- Black/White Plate
Key Features:
Product Information
| head | Tilting trinocular viewing head, 5-45 degree adjustable; binocular: trinocular= 100:0 or 0:100; interpupillary distance 50-76mm; fixed eyepiece tube with lock screw |
| Viewing | 30 degree inclined trinocular head; binocular: trinocular=50: 50; interpupillary distance 50-76mm; fixed eyepiece tube with lock screw |
| Eyepiece | High eye-point wide field plan eyepiece PL10X22mm, diopter adjustable |
| High eye-point wide field plan eyepiece PL15X16mm, diopter adjustable | |
| High eye-point wide field plan eyepiece PL20X12.5mm. diopter adjustable | |
| Zoom range | Zoom range: 0.63X-8X zoom ratio: 12.5 : 1: built-in aperture diaphragm; click stop for 0.63X. 0.8X. 1X. 1.25X. 1.6X. 2X. 2.5X. 3.2X. 4X. 5X. 6.3X. 8X |
| Main objective | 0.5main objective,working distance70.5mm |
| 1X main objective, working distance 78mm | |
| 1.5X main objective,working distance31. 1mm | |
| 2X main objective, working distance 20mm | |
| Body | Coarse and fine coaxial focus system, integrated body with focus holder, coarse range: 50mm. fine precision 0.002mm |
| Base | Plan base without illumination, with black & white plate (dia. 100mm) |
| Plan base with transmitted illumination (work with external 5W LED fiber): built-in 360 degree rotatable mirror, location adjustable | |
| Ultra-thin base, multi-LED (5W), with digital readout of light intensity and color temperature (3200-5600K) | |
| Illumination | 5W LED light box (size: 270X100X130mm) with single fiber (500mm), color temperature 5000-5500K; operating voltage 100-240VAC/50-60Hz, output 12V |
| LED ring lamp (200 bulbs) | |
| Camera adapter | 0.5X/0.65X/1X C-mount |
Camera Specifications:
| Sensor | Sony IMX178(C) 1080P/5MP | Sony IMX178(C) 1080P/8MP |
| Pixel (m) | 2.4 x 2.4 | 2.4 x 2.4 |
| FPS Resolution | 6001920x1080 (HDMI) | 60@1920x1080 (HDMI) |
| 2501920x1080 (WiFi) | 25@1920x1080 (WiFi) | |
| USB Mouse | Connect USB mouse for easy operation with embedded XCamView software | Connect USB mouse for easy operation with embedded XCamView software |
| USB2.O | Connect USB flash drive to save pictures and videos Connect 5C WLAN module to transfer video wirelessly in real time | Connect USB flash drive to save pictures and videos Connect 5G WLAN module to transfer video wirelessly in real time |
| SD | Comply with SD103.O standard and SD card could be inserted for video and images saving | Comply with SD103.O standard and SD card could be inserted for video and images saving |
| HDMI | Comply with HDMI1.4 standard. 4K/1080P format video output and supporting automatic switch between 4K and 1080P format according to the connected monitors | Comply with HDMI1.4 standard. 4K/1080P format video output and supporting automatic switch between 4K and 1080P format according to the connected monitors |
| Other Specifications for HDMI Output | ||
| UI Operation | With USB Mouse | |
| Image Capture | JPEG Format with 5M Resolution in SD Card(XCAM1080PHB) | JPEG Format with 5M Resolution in SD Card(XCAM1080PHB) |
| Video Record | ASF Format 1080P 30fps in SD Card | ASF Format 1080P 30fps in SD Card |
| Camera Control Panel | Including Exposure, Gain, White Balance, Color Adjustment, Sharpness and Denoising Control | Including Exposure, Gain, White Balance, Color Adjustment, Sharpness and Denoising Control |
| Toolbar | Including Zoom, Mirror, Comparison, Freeze, Cross, Browser Function | Including Zoom, Mirror, Comparison, Freeze, Cross, Browser Function |
