Optimum Digital Microscope
Regular price
Rs. 590,999.00
Description
Description
- Description
- 20mm Wide Field Eyepieces
- Swinging Adjustment of View
- Ring Illumination Light
- Auxiliary Lens
- Trinocular with Camera Option
- LED Incident and Transmittal Light (Standard)
- Integrated Control for LED Light
- Black/White Plate
Key Features:
Product Information
| OPTICAL SYSTEM | GREENOUGH Stereoscopic |
| Objective | Plan Achromatic Objective 1x |
| Viewing Body | Integated Binocular, 20 degree |
| EYEPIECE | Widefield 10x/22mm (Interchangeable), 53- 75mm IPD |
| ZOOM RATIO | 01:10 |
| ZOOM OBJECTIVE | 0.7x-4.5x |
| MAGNIFICATION RANGE | 8x to 80x Continuous (with 10x eyepiece) |
| WORKING DISTANCE | 78mm. |
| EYE GUARDS | Rubber, Retractable |
| OBJECT FIELD DIAMETER | 6.6 to 28.5 mm |
| ILLUMINATION CONTROL | Incident / Transmitted ("Oblique" Settings) / Combined illustration control buttons with rheostat dial for light intensity control |
| INCIDENT LIGHT METHOD | LED 3.3W with intensity control. |
| TRANSMITTED LIGHT | 3.3 W LED super bright glow screen, low heat emission |
| LED SERVICE LIFE | Approx 6,000 hours |
| LIGHT QUALITY | Homogeneous daylight (6500°K), free of UV and IR emissions |
Camera Specification
| Sensor | Sony IMX178(C) 1080P/5MP | Sony IMX178(C) 1080P/8MP |
| Pixel (m) | 2.4 x 2.4 | 2.4 x 2.4 |
| FPS Resolution | 6001920x1080 (HDMI) | 60@1920x1080 (HDMI) |
| 2501920x1080 (WiFi) | 25@1920x1080 (WiFi) | |
| USB Mouse | Connect USB mouse for easy operation with embedded XCamView software | Connect USB mouse for easy operation with embedded XCamView software |
| USB2.O | Connect USB flash drive to save pictures and videos Connect 5C WLAN module to transfer video wirelessly in real time | Connect USB flash drive to save pictures and videos Connect 5G WLAN module to transfer video wirelessly in real time |
| SD | Comply with SD103.O standard and SD card could be inserted for video and images saving | Comply with SD103.O standard and SD card could be inserted for video and images saving |
| HDMI | Comply with HDMI1.4 standard. 4K/1080P format video output and supporting automatic switch between 4K and 1080P format according to the connected monitors | Comply with HDMI1.4 standard. 4K/1080P format video output and supporting automatic switch between 4K and 1080P format according to the connected monitors |
| Other Specifications for HDMI Output | ||
| UI Operation | With USB Mouse | |
| Image Capture | JPEG Format with 5M Resolution in SD Card(XCAM1080PHB) | JPEG Format with 5M Resolution in SD Card(XCAM1080PHB) |
| Video Record | ASF Format 1080P 30fps in SD Card | ASF Format 1080P 30fps in SD Card |
| Camera Control Panel | Including Exposure, Gain, White Balance, Color Adjustment, Sharpness and Denoising Control | Including Exposure, Gain, White Balance, Color Adjustment, Sharpness and Denoising Control |
| Toolbar | Including Zoom, Mirror, Comparison, Freeze, Cross, Browser Function | Including Zoom, Mirror, Comparison, Freeze, Cross, Browser Function |
